gled

World on the outside of a sphere.

World on the outside of a sphere - closer look.

Close-up on a dragon-fly chopper.

Close-up on an airplane.

World on the outside of a torus.

World on the outside of a torus - closer look.

World on the inside of a torus.

World on the inside of a torus.

World on a flat rectangle.

World on the inside of a sphere.

Primary charged particles in a simulated central lead-lead event.

Simulated particle kinematics and simulated detector hits.

Time Projection Chamber: simulated detector response and reconstructed clusters (yellow). Clusters are found from detector-data and are used for track reconstruction.

Time Projection Chamber: simulated detector hits (blue) also plotted.

Reconstructed tracks (yellow), clusters (magenta) and the simulated kinematics (stippled).

Reconstruction of a neutral particle (short lived kaon) decay. Yellow: reconstructed tracks; stippled: simulated trajectories.

Core of the visualization framework is based on ROOT's I/O and data-analysis tools.

ROOT object browser pointed at Visualization Summary Data file, simulated particle record.

A view of ALICE detector geometry.

Overlaps and extrusions present in current ALICE detector description (marked by red points).

A simulated proton-proton colision resulting in a production of Higgs particle (event generated with Pythia-6).

Toruses coarsened to different number of edges (using GTS library).

A screenshot of a distributed analysis of ALICE simulated data in Grid environment using gLite and PROOF. This application was shown at SuperComputing-2004 conference in Pittsburgh, USA.

DivX capture of a distributed analysis of ALICE simulated data in Grid environment using gLite and PROOF. Key-frame animation is not Gled's strongest point. Yet.

Gled as a meta-presentation engine (using slide show class MultiBoard).

A method call widget.

GTS surfaces generated from formulas. (7-Jun-2004)

After some playing with RectTerrains, a GTS surfaces and SMorph. (28-May-2004)

New capabilites: GL text and gradients imported from gimp. (13-Jun-2004)

Import of 2D ROOT histograms into RectTerran: application of smoothing and custom color gradient. (13-Jun-2004)

Full screenshot of Gled-1.2.1. (30-Jul-2003)

The images.C demo showing new additions to Geom1 libset. (30-Jul-2003)

An example of a Weaver Symbol using classes WSSeed and WSPoint from Geom1. (8-Jul-2003)

An example of a Weaver Symbol. (8-Jul-2003)

Full screen-shot for freshmeat submission. 1600x1200 (4-Jun-2003)

A detail from GTS demo with enabled transparency. (4-Jun-2003)

Full screen containing GL window (Pupil), object browser (FTW_Nest), message output window and some object control windows. 1600x1200 (22-Mar-2003)

Object browser (FTW_Nest) showing an object graph in link mode, where pointers to objects are represented on the right side of the window. (22-Mar-2003)

GL window (Pupil) with some junk (a tree-ordered cluster of Spheres over a RectTerrain and a Rect). Notice transparency ... or sth. (22-Mar-2003)

Full-view of an instance of a spherical morph class (SMorph from Geom1 libset). (22-Mar-2003)

GL window (Pupil) with an open-ended spherical morph (SMorph) over a rectangular terrain. (22-Mar-2003)

Object browser (FTW_Nest) showing an object-graph in custom mode, where members to be shown can be selected by name. In this particular case state of nodes in a Gled cluster is shown. (22-Mar-2003)

Pupil (render window) with a RectTerrain object and a grid of spherical distance minimizators (Spherors coupled to WarmAmoeba minimizator). (22-Mar-2003)

Full-view of an instance of SaturnInfo class, representing a node in a hierarchic server-client structure. (22-Mar-2003)

Gled console running CINT (C/C++ interpreter shell, inherited from ROOT) in action. (22-Mar-2003)

Gled message window. (22-Mar-2003)

GL window (Pupil) showing a RectTerrain and a SMorph in wireframe mode. (22-Mar-2003)

GL window (Pupil) showing a RectTerrain and a SMorph in fill mode. (22-Mar-2003)
